NRT 200 B Axial-radial Cylindrical Roller Bearings
| Item no. | NRT 200 B |
| Manufacturer: FIJ |
Equivalent: SKF |
| Measurement | Metric |
| Roller Bearing Type | Cylindrical |
| Load direction | Combined Radial and Thrust |
| Inside Diameter | 200 mm |
| Inside Diameter Tolerance | -0.015mm to 0 |
| Outer Diameter | 300 mm |
| Outer Diameter Tolerance | -0.018mm to 0 |
| Height | 45 mm |
| Height Tolerance | -0.20mm to 0 |
| Shoulder Diameter Inner Ring - Large Shoulder | 274 mm |
| Outer Ring (Housing Washer) Width | 15 mm |
| Distance | 30 mm |
| Inner Ring (Shaft/Locating Washer) Hole Pitch Circle Diameter | 215 mm |
| Outer Ring (Housing Washer) Hole Pitch Circle Diameter | 285 mm |
| Inner Ring (Shaft/Locating Washer) Through Hole | 7 mm |
| Inner Ring (Shaft Washer) Sinkhole | 11 mm |
| Outer Ring (Housing Washer) Through Hole | 7 mm |
| Inner Ring (Shaft Washer) Sinkhole Depth | 6.2 mm |
| Outer Ring (Housing Washer) Chamfer Dimension r1 (min.) | 0.6 mm |
| Chamfer Dimension r2 (min.) | 0.3 mm |
| Basic dynamic load rating | 21020 lbf |
| Basic static load rating | 60699 lbf |
| Dynamic Axial Load | 19109 lbf |
| Static Axial Load | 141624 lbf |
| Max Speed (X1000 rpm) | 0.34 |
| Axial Preload | 2.9 kN |
| Axial Unloading Force | 6.2 kN |
| Frictional Moment | 14 N·m |
| Axial Stiffness For Preload A (sets of two brgs back-to-back or face-to-face) | 12000000 kN/µm |
| Axial Stiffness For Preload B (sets of two brgs back-to-back or face-to-face) | 6500000 kN/µm |
| Moment Stiffness | 75 kN·m/mrad |
| Material, Ring | Chrome Steel |
| Roller Material | Chrome Steel |
| Material, Cage | Brass cage |
| Lubricant | Grease, Oil |
| Temperature Range | -30° to 110 °C |
| Mass | 9.5 kg |
